- MFR: Zoll
Description
Additional Information
| Equipment Type | Diagnostic Intruments |
|---|---|
| Brand | Zoll |
| Condition | Factory New |
| Warranty | 1 Year |
Specifications
| Defibrillator | |
| Protocol | Semi-Automatic |
| Waveform | Zoll Rectilinear Biphasic |
| Charge Hold Time | 30 seconds |
| Energy Selection | Factory preprogrammed selection |
| Charge Time | Less than 10 seconds with a new battery |
| Pre-Shock Pause | Less than 5 seconds with a new battery |
| Patient Safety | All patient connections are electrically isolated |
| Electrodes | Zoll CPR Uni-Padz |
| Self-Test | User-configurable automatic self-test every day or every 7 days (Default: every 7 days). Monthly full-energy test. |
| Automatic Self-Test Checks | Battery capacity, status, and expiration; electrode connection and expiration; ECG and change/discharge circuits; microprocessor hardware and software; CPR circuitry and pads sensor; auto circuitry. |
| CPR Metronome Rate | Constant 105 (+/-2) CPM |
| Depth Measurement | 0.75" to 4" (1.9 cm to 10.2 cm) |
| Defibrillation Advisory | Evaluates electrode connection and patient ECG to determine if defibrillation is required |
| Shockable Rhythms | Ventricular fibrillation with average amplitude of >100 microvolts and wide complex ventricular tachycardia with rates >150 BPM for adults, >200 BPM for pediatrics. |
| Impedance Measurement Range | 10 ohms to 300 ohms |
| Display Format | High-resolution LCD with capacitive touch panel |
| Display Screen Size | 2.2" x 3.7" (5.4 cm x 9.5 cm) |
| Display Sweep Speed | 25 mm/sec |
| Display Viewing Speed | 3.84 seconds |
| Data Recording & Storage | User-configurable for 1 or 2 clinical events for a total of 120 minutes. With voice recording enabled, total of 60 minutes. |
| Data Recovery | Controlled by touchscreen, uploaded to USB memory stick, or RescueNet CaseReview over a Wi-Fi network. |
| Internal Clock Synchronization | Coordinated Universal Time (UTC) synchronization occurs when communicating with the Zoll Online server. |
| Device | |
| Size | 5" x 9.3" x 9.7" (12.7 cm x 23.6 cm x 24.7 cm) |
| Weight | 5.5 lb (2.5 kg) |
| Power | Lithium manganese dioxide battery pack |
| Wireless | 802.11 a/b/g/n |
| Security | WPA 1, WPA 2, WPA Personal, WPA Enterprise |
| Port | USB 2.0 |
| Classification | Class II and internally powered per EN60601-1 |
| Design Standards | Meets applicable requirements of EN 60601-1, IEC 60601-1-11, IEC 60601-2-4 |
| Environmental | |
| Operating Temp | 32°F to 122°F (0°C to 50°C) |
| Storage Temp | -22°F to 158°F (-30°C to 70°C) |
| Humidity | 10% to 95% RH, non-condensing |
| Vibration | IEC 60068-2-64, RTCA/DO-160G, EN 1789 |
| Shock | IEC 60068-2-27; 100 G |
| Altitude | -381 m to 4573 m (-1250 to 15,000 ft) |
| Ingress Protection | IP55 |
| Drop Test | 1 m (3.28 ft) |
| Battery | |
| Type | Disposable, sealed lithium manganese dioxide |
| Capacity | 140 shocks @ 200J or 6 hrs monitoring (2-min CPR) |
| Standby Life | 5 years with weekly self-test |
| Shelf Life | Store for up to 2 years @ 77°F (23°C) |
| Size | 1" x 5.2" x 3.5" (27.75 mm x 133 mm x 88 mm) |
| Weight | 0.7 lb (317.5 g) |
| Nominal Voltage | 12 volts |
| CPR Uni-Padz | |
| Shelf Life | 5 years |
| Conductive Gel | Polymer Hydrogel |
| Conductive Element | Tin |
| Packaging | Multilayer foil laminate pouch |
| Impedance Class | Low |
| Cable Length | 56 ±1.5 in. (142 ±3.8 cm) |
| Standards | Meets requirements of IEC 60601-2-4, 2010 |
- MFR: Zoll
